CONVOY T9

◆ PARAMETER

Required battery type:

2 * AA (1.5V alkaline battery or 1.2V NiMH battery),
or 2 * 14500 button-top 3.7V lithium-ion rechargeable battery.
or 2 * 1.6V-1.8V lithium metal primary disposable batteries. 【The driver has been updated.】

◆ 12 groups:

if flashlight is turned on,tap the switch 10 times quickly to enter into config mode.(On a visual interface,as long as you click on an option, it means that the option is selected. The flashlight has no visual interface. It flashes to represent an option, and "tap the switch in the flashing process" means to select the option.)

OPTION 1

Option 1 (normal-flash 1 time buzz-flash): tap the switch to enter into sub-option to select the mode group,If the user has no operation, the config mode will enter option 2.

01

sub-option 1.1 (normal-flash 1 time) : tap the switch to select mode group 1 (1%.10%.30%.100%)

02

sub-option 1.2 (normal-flash 2 times) : tap the switch to select mode group 2 (1% 10%.35%.100%.strobe.biking.batcheck)

03

sub-option 1.3 (normal-flash 3 times) : tap the switch to select mode group 3 (100%.35%.10%.1%)

04

sub-option 1.4 (normal-flash 4 times) : tap the switch to select mode group 4 (1%.20%.100%.strobe.biking.batcheck.sos)

05

sub-option 1.5 (normal-flash 5times) : tap the switch to select mode group 5(1%.20%.100%)

06

sub-option 1.6(normal-flash 6times) : tap the switch to select mode group 6(100%.20%.1%)

07

sub-option 1.7 (normal-flash 7times) : tap the switch to select mode group 7(1%.10%.50%.strobe.biking.batcheck.sos)

08

sub-option 1.8 (normal-flash 8 times) : tap the switch to select mode group 8 (1%.10%.50%)

09

sub-option 1.9 (normal-flash 9 times) : tap the switch to select mode group 9 (50%.10%.1%)

10

sub-option 1.10 (normal-flash 10 times) : tap the switch to select mode group 10 (20%.100%)

11

sub-option 1.11 (normal-flash 11 times) : tap the switch to select mode group 11(100%.20% strobe)

12

sub-option 1.12 (normal-flash 12 times) : tap the switch to select mode group 12(100%)

OPTION 2

Option 2 (normal-flash 2 times buzz-flash): tap the switch to active the mode memory or inactive it,If the user has no operation,flashlight will enter into the last mode.

◆ 14500 battery-check instructions:

Notice that there is no battery-check function if flashlight is powered by the 1.5V battery
